8KW DC Load Bank Data Center
8KW AC/DC Resistive load bank with rack mounted type, local manual with button or switch control, suitable for Data Center, service room use etc.
Dimension (W*D*H)：
484*600*267mm
Weight：
25KG
Introduction:
The rack-mounted load bank for testing in the data computer room has a built-in pure resistive load; the power input adopts segmented combination control, which can simulate the power usage and heat dissipation of server IT equipment in the computer room. By using dummy loads for integrated testing, we ensure the effective operation of the computer room power supply system, air conditioning fresh air system, lightning protection grounding system, monitoring system, computer room comprehensive environment, computer room IT micro-environment, and computer room decoration project, and verify that the design and operation are achieved degree of requirement.
Main advantages:
A. Resistive load adopt new type of consumption components,Resistance thermal shrinkage and sealing installed in stainless steel tube, steel tube with insulation radiator, good moisture and corrosion resistance, good heat dissipation, high insulation, safe and reliable. High power density of resistance elements, 3-phase current balance, no red heat phenomenon, The independent cooling fan ensures the heat dissipation and service life of the whole system.
B. The load overcomes the fact that the water resistance test system cannot accurately control the resistance value, the water is easy to boil, easy to scale, can not be subjected to sudden loading/depression load reduction test, and is difficult to control.It is an upgraded product of water resistance. This product has high safety, low maintenance cost, low noise and strong overload capability.
C. The fan adopts a small axial fan, with large wind volume, good heat dissipation, low noise and other characteristics.
Specification:
Product Name | SP-AC220V/DC270V-8KW-R AC/DC Resistive Load Bank |
Rated Voltage | AC220V & DC270V, 50/60Hz |
Rated Power | 8KW |
Power factor | PF=1 |
Load steps | 100W, 200W, 200W, 500W, 1KW, 2KW, 2KW, 2KW (Adjust from 100W~8KW) Remarks: 8 steps can be arbitrary combination. |
Load test accuracy | -5%~+2% |
Protection function | Over temperature protection, Buzzer and light alarm.Emergency stop protection |
Work power | Single-phase AC220, 50/60Hz (Power cord input) |
Work Mode | Continuous work |
Cooling Mode | Force-air cooling; air entry from front and outlet from back |
Control mode | Local manual control with button |
Wire connection | 1.Terminal (L N ): connected with tested equipment 2. Socket for Fan: 1 pcs power cord (1.5m) |
Color of load bank | Optional (Orange/ Black) |
Move mode | Two handles |
Ambient Temperature | -10℃～+50℃ |
Humidity | ≤95% |
Max protection grade | IP20 (for Indoor use) |
Dimension (W*D*H) | About 484*600*267mm (Size is subject to finished device) |
Weight | About 25KG (Weight is subject to finished device) |
Language | English (Default) |
Application | Data center room, Service room |
| Material | Alloy resistor (high temperature resistant which can work up to 1300℃ with stable electrical performance and small temperature drift coefficient (5*10-5/℃) |
Remarks: Special specifications can be customized according to customer requirements (Rated voltage, Rated power, Power supply voltage, box size etc).
Other similar products:
1. What is the 8KW DC Load Bank used for?
The 8KW DC Load Bank applies a controlled DC load to test DC power sources — batteries and battery strings, DC UPS, rectifiers, DC chargers and EV charger power stages — for capacity, discharge and maintenance testing.
2. Can I test battery capacity with it?
Yes — constant-current or constant-resistance discharge at the required rate is the standard battery capacity test; confirm the model's current/voltage range and termination settings against your battery bank.
3. Do I need AC or DC load banks?
AC sources need AC load banks; DC sources (batteries, DC chargers) need DC units. For AC generator/UPS testing see our load bank type guide; choose DC for battery and DC charger work.
4. Which voltage and current ranges does the 8KW DC Load Bank cover?
DC load banks are configured to a nominal DC voltage and rated discharge current/power — give us your battery or charger DC bus voltage and required discharge rate and we will match the model.
